1977 Volvo 244 problems
The Volvo 200 Series (or 240 and 260 Series) is a range of mid-size cars produced by Swedish company Volvo Cars from 1974 until 1993, with more than 2.8 million total units sold worldwide. Like the Volvo 140 Series (1966 to 1974), from which it was developed, it was designed by Jan Wilsgaard.
The series overlapped production of the Volvo 700 Series (1982 to 1992). As the 240 Series remained popular, only the 260 Series was displaced by the 700 Series, which Volvo marketed alongside the 240 for another decade. The 700 was replaced by the 900 Series in 1992, a year before the 240 was discontinued. Production of the 240 ended on 14 May 1993, after nearly 20 years, with the basic platform and architecture lasting 27 years, if the production run of the original 140 Series is aggregated.
History
The Volvo 240 and 260 series were introduced in the autumn of 1974, and was initially available as six variations of the 240 Series (242L, 242DL, 244DL, 244GL, 245L and 245DL) and two variations of the 260 Series (264DL and 264GL). The 240 Series was available as a sedan (with two or four doors) or a station wagon, however, the 260 Series was available as a coupé (262C Bertone), two-door sedan, four-door sedan, or station wagon. The 200 looked much like the earlier 140 and 164, they shared the same basic body shell and were largely identical from the cowl rearward. However, the 200 incorporated many of the features and design elements tried in the Volvo VESC ESV in 1972, which was a prototype experiment in car safety. The overall safety of the driver and passengers in the event of a crash was greatly improved with very large front and rear end crumple zones. Another main change was the new engines offered, which were of an overhead cam design based on the earlier B20. The 260 series also received a V6 engine in lieu of the 164's inline-six.
The 200 Series had MacPherson strut-type front suspension, which increased room around the engine bay, while the rear suspension was a modified version of that fitted to the 140 Series. The steering was greatly improved with the introduction of rack-and-pinion steering, with power steering fitted as standard to the 244GL, 264DL and 264GL, and there were some modifications made to the braking system (in particular the master cylinder).
The front end of the car was also completely restyled with a "shovel nose" which closely resembled that of the VESC prototype vehicle – that being the most obvious change which made the 200 Series distinguishable from the earlier 140 and 160 Series. Other than all the changes mentioned above, the 200 Series was almost identical to the 140 and 160 Series from the bulkhead to the very rear end. In 1978, a facelift meant a redesigned rear end for sedans, with wraparound taillights and a trunk opening with a lower lip. The dashboard was derived from the safety fascia introduced for the 1973 model year 100 Series - the main change for the 200 Series was the adoption of slatted "egg crate" style air vents in place of the eyeball style vents used in the 140/160 and the square clock. All models were available with a choice of four-speed manual or a three-speed automatic transmission. Overdrive was also optional on the manual 244GL, while a five-speed manual gearbox was optional on the 264GL and 265GL.
In the autumn of 1975 (for the 1976 model year in America), the 265 DL estate became available alongside the existing range, and this was the first production Volvo estate to be powered by a six-cylinder engine. The choice of gearboxes was also improved, with overdrive now available as an option in all manual models except the base-model 242L and 245L. As before, a three-speed automatic was optional in every model. The B21A engine gained three horsepower; a new steering wheel and gearknob were also introduced.
At the 1976 Paris Motor Show Bertone first showed the stretched 264 TE, a seven-seat limousine on a 3,430 mm (135.0 in) wheelbase, although it had entered production earlier. The raw bodies were sent from Sweden to Grugliasco for lengthening, reinforcing, and finishing. Carl XVI Gustav of Sweden used one, as did much of East Germany's political leadership.
For 1977 the B19A engine with 90 PS (66 kW) replaced the B20A in most markets, although the old pushrod type soldiered on for another two years in some places. This is also the year that the sportier 242 GT arrived.
In 1978 the grille was altered, now with a chrome surround. Rear view mirrors were now black, while the front seats were changed as were the emblems, while interval wipers were introduced. 1978 models were also the first 240s to receive a new paint formula, to help solve the severe rust problems in previous model years.
The 1979 model year brought a full facelift front and rear, the most obvious change being the adoption of flush fitting square headlamps on the DL or rectangular headlamps on the GL, GLE in place of the recessed circular units. The sedans received new wraparound rear lamp clusters and a restyled leading edge to the trunk lid, while the rear of the wagons remained unchanged. The GLE was added while the L was cancelled, and the six-cylinder diesel arrived late in the year. For 1980, the sporty GLT arrived, replacing the GT. For 1981 there was yet another new grille, while the station wagons received new, wraparound taillights. The B21A gained some four horsepower, now 106 PS (78 kW), while the carburetted B23A with 112 PS (82 kW) was introduced in some markets. The Turbo arrived, while six-cylinder models now had a more powerful 2.8-liter engine. 1981 also saw the dashboard altered significantly, which a much larger binnacle in order to bring the radio and clock within the driver's line of sight. The instrument pod itself, which had been unaltered since the 1973 model year 100 Series, was also redesigned.
Incremental improvements were made almost every year of the production run. One of the major improvements was the introduction of the oxygen sensor in North America in late 1976 (1977 models), which Volvo called Lambda Sond and developed in conjunction with Bosch. It added a feedback loop to the Jetronic fuel injection system already in use, which allowed fine-tuning of the air and fuel mixture and therefore produced superior emissions, drivability and fuel economy.
For the 1983 model year, Volvo dropped the DL and GLE labels, selling the cars simply as 240s. In the domestic Swedish market, the 240 could be had with a 2.1 or 2.3-liter engine (more options were available in export), but the bigger engine always came coupled with a five-speed transmission and tinted windows. The 1983s also received wider side trim and all models had the larger taillights introduced on the previous year's GLT model. A B23E-engined GLE variant was also added (not available with two doors). Buyers protested against the lack of grades and they returned for 1984. A new manual gearbox also arrived for 1984, while a four-speed automatic option was available in the GL. The GLT and Turbo versions received a taller grille.
While Volvo had been planning to discontinue the 200-series since the early 1980s, the design kept selling well and Volvo provided steady updates. In late 1991, for the 1992 model year, it received 160 detail improvements including changes to the heater controls, heated rear view mirrors, and revised front seats. For the final, 1993 model year, air conditioning units were upgraded to use R-134a rather than the ozone-depleting R-12 (Freon).
About one-third of all 240s sold were station wagons, which featured very large cargo space of 41 cubic feet (1.2 m3). They could be outfitted with a rear-facing foldable jumpseat in the passenger area, making the wagon a seven-passenger vehicle. The jumpseat came with three-point seat belts, and wagons were designed to have a reinforced floor section, protecting the occupants of the jumpseat in the event of a rear-end collision.
A 1993 Volvo 240DL was driven by IKEA founder Ingvar Kamprad, who stopped driving it when he was told the car was too dangerous due to outdated safety design two decades later.
The last 200 produced was a blue station wagon built to the Italian specification and named the "Polar Italia", currently displayed at the Volvo World Museum. It was manufactured the 14th May 1993.
Social links
Common 1977 Volvo 244 problems
Based on complaints from owners of the Volvo 244 1977, common problems with this car include issues with the fuel system, engine oil leaks, power loss, transmission problems, and electrical issues.
- Engine Oil Leaks:
- Engine oil leaks were another prevalent issue reported by Volvo 244 1977 owners. These leaks could stem from various sources like the valve cover gasket, camshaft seal, or oil pump seal, potentially leading to low oil levels and engine damage if not promptly addressed.
- Power Loss:
- Power loss was a common complaint among Volvo 244 1977 owners. This issue could result from factors such as a clogged air filter, worn spark plugs, failing ignition system, or fuel system problems like a clogged fuel filter or failing fuel pump.
- Transmission Problems:
- Transmission issues, particularly slipping or failure to shift, were reported by owners of the Volvo 244 1977, especially in automatic transmissions. Causes could include worn or damaged transmission components, low fluid levels, or a failing torque converter.
- Electrical Issues:
- Electrical problems like a faulty alternator, starter, or battery drain were also common complaints among Volvo 244 1977 owners. These issues could lead to starting failures or other electrical malfunctions like flickering headlights or dashboard gauge issues.
By addressing these common problems with proper maintenance and care, owners of the Volvo 244 1977 can mitigate these issues and ensure the longevity and reliability of their vehicle.
What is the difference between Volvo 240 and 244?
A 244 was a 200 series, 4 cylinder, 4 door saloon. A 245 was a 200 series, 4 cylinder, 5 door estate. A 240 was the later rebranded and simplified version to incorporate both body styles into one name of "240".
What is the top speed of the Volvo 244 DL?
Performance
| 0 - 40 kph | 2.7 s |
|---|---|
| 40 - 80 kph (4) | 10.5 s |
| 40 - 100 kph (4) | 16.7 s |
| 40 - 120 kph (4) | 24.5 s |
| Top speed | 162 kph (101 mph) |
How much horsepower does a Volvo 244 GL have?
| Volvo 244 2.3 GL Engine Technical Data | |
|---|---|
| Compression Ratio : | 10.3 |
| Horsepower : | 110 HP / 112 PS / 82 kW @ 5000 rpm |
| Maximum torque : | 136 lb-ft / 185 Nm @ 2500 rpm |
| Drive wheels - Traction - Drivetrain : | RWD |
What is the life expectancy of a Volvo 240?
What is Volvo 240 lifespan? The estimated lifespan of a Volvo 240 is 380,000mi, before reaching the life expectancy upper limit. Fuel type is a major factor when looking into a vehicles lifespan/life expectancy.
What is the difference between Volvo 240 and 244?
A 244 was a 200 series, 4 cylinder, 4 door saloon. A 245 was a 200 series, 4 cylinder, 5 door estate. A 240 was the later rebranded and simplified version to incorporate both body styles into one name of "240".
What is the top speed of the Volvo 244 DL?
Performance
| 0 - 40 kph | 2.7 s |
|---|---|
| 40 - 80 kph (4) | 10.5 s |
| 40 - 100 kph (4) | 16.7 s |
| 40 - 120 kph (4) | 24.5 s |
| Top speed | 162 kph (101 mph) |
What size engine is in the Volvo 244?
VOLVO 244 2.0L 4MT (97 HP)
| ENGINE SPECS - 2.0L 4MT (97 HP) | |
|---|---|
| Cylinders: | L4 |
| Displacement: | 1986 cm3 |
| Power: | 71 KW @ 5500 RPM 97 HP @ 5500 RPM 95 BHP @ 5500 RPM |
| Torque: | 116 lb-ft @ 2500 RPM 157 Nm @ 2500 RPM |
How much horsepower does a Volvo 244 GL have?
| Volvo 244 2.3 GL Engine Technical Data | |
|---|---|
| Compression Ratio : | 10.3 |
| Horsepower : | 110 HP / 112 PS / 82 kW @ 5000 rpm |
| Maximum torque : | 136 lb-ft / 185 Nm @ 2500 rpm |
| Drive wheels - Traction - Drivetrain : | RWD |
1977 Volvo 244 car problems categorized by type of issue
After analyzing all complaints sent to the NHTSA and researching popular Volvo 244 problems, we found that the most common problems with these 2023 model year vehicles are:
- Power train problems
The graph below shows statistics for all 1977 Volvo 244 vehicle components and the number of complaints received.
1977 Volvo 244 complaints
The NHTSA has received 1 complaints about various vehicle components related to the 1977 Volvo 244.
POWER TRAIN PROBLEM
- Date Of Incident: 1997-07-01
- Components: POWER TRAIN
- Summary: UNIVERSAL JOINT FAILURE. *AK
1977 Volvo 244 recalls
The National Highway Traffic Safety Administration (NHTSA) has issued 2 recalls for different components of the 1977 Volvo 244.
- Manufacturer: VOLVO OF AMERICA CORP.
- Components: FUEL SYSTEM, GASOLINE:STORAGE:TANK ASSEMBLY
- Summary: THE INVOLVED VEHICLES CONTAIN A POTENTIALLY DEFECTIVE PRESSURE CONTROL VALVE IN THE EVAPORATIVE EMISSION CONTROL SYSTEM WHICH, THROUGH EXCESS PRESSURE OVER EXTENDED PERIODS, COULD CAUSE METAL FATIGUE AND EVENTUALLY FUEL VAPORS TO BE EMITTED INTO THE ATMOSPHERE THROUGH HAIRLINE CRACKS IN THE FUEL TANK.
- Remedy: DEALER WILL INSPECT THE TANK AND MAKE REPLACEMENTS, IF NECESSARY. THE VALVE WILL BE REPLACED TO CORRECT THE EMISSION AND SAFETY-RELATED PROBLEMS. CERTAIN VEHICLES WILL REQUIRE INSTALLATION OF A FILLER INLET FUEL TRAP AND A FEEDER PUMP TO ELIMINATE THE POSSIBILITY OF FUEL SURGE AND VAPOR LOCK.
- Manufacturer: VOLVO OF AMERICA CORP.
- Components: POWER TRAIN:AXLE ASSEMBLY:AXLE SHAFT
- Summary: THE REAR WHEEL BEARINGS ON THE INVOLVED VEHICLES, MAY HAVE RECEIVED AN INADEQUATE AMOUNT OF LUBRICATION. THIS CONDITION WOULD INITIALLY CAUSE THE ROLLER BEARINGS TO DEVELOP A RUMBLING NOISE.
- Remedy: THE DEALER WILL EITHER LUBRICATE THE BEARINGS OR REPLACE THEM WITH NEW BEARINGS AND SEALS WITH LUBRICATION AT NO CHARGE TO OWNER.
