The BMW X5 is a mid-size luxury crossover SUV produced by BMW. The X5 made its debut in 1999 as the E53 model. It was BMW's first SUV. At launch, it featured all-wheel drive and was available with either a manual or automatic gearbox. The second generation was launched in 2006, and was known internally as the E70. The E70 featured the torque-split capable xDrive all-wheel drive system mated to an automatic gearbox. In 2009, the X5 M performance variant was released as a 2010 model.

BMW marketed the X5 officially as a "Sports Activity Vehicle" (SAV), rather than an SUV, to indicate its on-road handling capability despite its large dimensions. The X5 signaled a shift away from the utilisation of body-on-frame construction, in favour of more modern monocoque chassis construction. Although the Mercedes-Benz M-Class was introduced more than a year prior to the X5, the X5 was the first to utilise a monocoque chassis. The M-Class used body-on-frame construction until its second generation.

The X5 is primarily manufactured in North America, at BMW Group Plant Spartanburg. Assembly operations also take place in Russia by Avtotor, along with operations in India, Indonesia, Malaysia, and Thailand. The X5 is also modified for armoured security versions, at the BMW de México Toluca plant.

The automaker's SAV series, which was started by the X5, has expanded with derivations of other number-series BMWs. This began in 2003 with the X3, and continued in 2008 with the X6 (which shares its platform with the X5).

Social links

Common 2009 Bmw X5 sav problems

The 2009 BMW X5, while not having a high number of complaints, does have a few trouble spots that are worth noting. One common issue is oil leaks, which are frequently mentioned in automotive forums.

Another problem that has been reported for the 2009 BMW X5 is melting taillights, which can cause warning lights to appear on the dashboard and pose a significant safety hazard.

It is important to note that these issues are not widespread and may not affect all 2009 BMW X5 vehicles. However, potential buyers should be aware of these problems and consider having the vehicle inspected by a qualified mechanic before making a purchase. Regular maintenance and inspections can help prevent these issues from occurring or escalating, ensuring the longevity and reliability of the vehicle.

How many miles can a 2009 BMW X5 last?

A BMW can last 150-200,000 miles with proper care and if you drive the national average of 13,500 miles per year, you can expect to drive your BMW for 10-15 years according to MotorAsk.

Is BMW X5 2009 a good car?

The 2009 BMW X5 is one of the best-handling midsize luxury SUVs you can buy. Whether driving on back roads or on an endless expanse of interstate, the X5 is a champ.

What is the best year of BMW X5 to buy?

The Best Years: 2019, 2022, 2023, 2024

2019, 2022, 2023, and 2024 are undeniably the best BMW X5 years in fourth generation linage. BMW's focus on refining and improving the X5 becomes evident in the 2019, 2022, 2023, and presumptively the 2024 models.

Is it safe to buy a used BMW X5?

Cons of Buying a Used BMW X5

You should check the worst years of production, where models had recurring problems such as water leaks, tailgate melting, and other safety hazards. Most notably, vehicles from 2008, 2009, 2012, 2013, and 2014 need to be avoided.

Is BMW X5 2009 a good car?

The 2009 BMW X5 is one of the best-handling midsize luxury SUVs you can buy. Whether driving on back roads or on an endless expanse of interstate, the X5 is a champ.

What is the common problem with BMW X5?

The gearbox plug sleeve seal is known for failing, causing the transmission oil to leak out of this area. If you have noticed that the gearbox oil is becoming low, this is the most likely cause.

How many miles can a 2009 BMW X5 last?

A BMW can last 150-200,000 miles with proper care and if you drive the national average of 13,500 miles per year, you can expect to drive your BMW for 10-15 years according to MotorAsk.

Is a BMW X5 expensive to maintain?

BMW X5 Major Service Costs: Common Issues & Repair Pricing

Time always takes a toll, and BMW X5 major service costs can come in at more than $1,400 per year when your vehicle ages out of its warranty. Of course, your mileage will vary.

2009 Bmw X5 sav complaints

The NHTSA has received 0 complaints about various vehicle components related to the 2009 Bmw X5 sav.

You can leave your car complaint via the special form below.

2009 Bmw X5 sav recalls

The National Highway Traffic Safety Administration (NHTSA) has issued 4 recalls for different components of the 2009 Bmw X5 sav.

2022-03-02

Manufacturer: BMW of North America, LLC
Components: ENGINE AND ENGINE COOLING:EXHAUST SYSTEM:EMISSION CONTROL:CRANKCASE (PCV)
Summary: BMW of North America, LLC (BMW) is recalling certain 2008-2013 1 Series Coupe (128i); 2007-2013 3 Series Coupe (328i, 328xi, 328i xDrive); 2007-2010 X3 SAV (X3 3.0si, X3 xDrive30i); 2008-2013 1 Series Convertible (128i); 2006-2011 3 Series Sedan (325i, 325xi, 328i, 328xi, 328i xDrive, 330i, 330xi); 2006-2012 3 Series Wagon (328i, 328i xDrive); 2007-2013 3 Series Convertible (328i); 2006-2010 5 Series Sedan (525i, 525xi, 528i, 528xi, 530i, 530xi); 2006-2007 5 Series Wagon (530xi); 2007-2010 X5 SAV (X5 3.0si, X5 xDrive30i); 2006-2008 Z4 Coupe (Z4 3.0si); and 2006-2011 Z4 Roadster (Z4 3.0i, Z4 3.0si, Z4 sDrive30i) vehicles. The heater for the positive crankcase ventilation (PCV) valve may short circuit.
Consequence: An electrical short can cause the PCV valve heater to overheat, increasing the risk of a fire while driving or, soon after driving when parked.
Remedy: This recall supersedes and expands previous NHTSA recalls 17V-683 and 19V-273. Dealers will install an electrical wiring harness with fuse protection for the PCV Valve heater in potentially affected vehicles, free of charge. This recall supersedes and expands previous NHTSA recalls 17V-683 and 19V-273. Vehicles previously repaired under the prior recalls will need to come back for the new recall remedy. The remedy is currently being developed. Interim owner notification letters informing owners of the safety risk were mailed on April 1, 2022. Owner notification letters were mailed on July 22, 2022. Owners may contact BMW customer service at 1-800-525-7417.

2016-02-05

Manufacturer: BMW of North America, LLC
Components: AIR BAGS:FRONTAL:DRIVER SIDE:INFLATOR MODULE
Summary: BMW of North America, LLC (BMW) is recalling certain model year 2008-2013 128i and 135i coupes and convertibles and 1 Series M coupes, 2006-2011 325i, 325xi, 328i, 328xi, 328i xDrive, 330i, 330xi, 335i, 335xi, 335i xDrive Sedans, 2009-2011 335d sedans, 2006-2012 325xiT, 328i and 328xi sports wagons, 2007-2013 328i, 328xi, 328i xDrive, 335i, 335xi, 335i xDrive, 335is and M3 Coupes and Convertibles, 2013-2015 X1 sDrive28i, X1 xDrive28i and X1 xDrive35i SAVs, 2007-2010 X3 xDrive30i SAVs, 2007-2013 X5 xDrive30i, X5 xDrive35i, X5 xDrive48i, X5 xDrive50i and X5 M SAVs, 2009-2013 BMW X5 xDrive35d SAVs, 2008-2014 X6 xDrive35i, X6 xDrive50i, and X6 M SACs, 2010-2011 BMW X6 xDrive50i SACs and 2008-2011 M3 Sedan vehicles. Upon deployment of the driver's frontal air bag, excessive internal pressure may cause the inflator to rupture.
Consequence: In the event of a crash necessitating deployment of the driver's frontal air bag, the inflator could rupture with metal fragments striking the driver or other occupants resulting in serious injury or death.
Remedy: BMW will notify owners, and dealers will replace the driver's frontal air bag module or inflator depending on the vehicle model, free of charge. The recall began March 9, 2018. Owners may contact BMW customer service at 1-800-525-7417.

2013-02-07

Manufacturer: BMW of North America, LLC
Components: SERVICE BRAKES, HYDRAULIC:POWER ASSIST
Summary: BMW is recalling certain model year 2007-2010 X5 SAV vehicles, manufactured September 12, 2006, through March 18, 2010 and equipped with an 8-cylinder engine. The brake vacuum pump may leak a small amount of lubricating oil into the hose. The contamination could result in a loss of power assist braking.
Consequence: The loss of power assist in braking could increase stopping distance and lead to a vehicle crash.
Remedy: BMW will notify owners, and dealers will replace the brake vacuum line with one that contains a check valve, free of charge. The recall began during March 2013. Owners may call BMW at 1-800-525-7417 or email BMW at [email protected].

2012-11-27

Manufacturer: BMW of North America, LLC
Components: STEERING:HYDRAULIC POWER ASSIST SYSTEM
Summary: BMW is recalling certain model year 2009-2012 X5 xDrive 35d SAV diesel vehicles manufactured September 1, 2008, through November 15, 2012. The engine belt idler pulley bolt could loosen and break over time.
Consequence: If the engine belt idler pulley bolt breaks, the vehicle may unexpectedly lose power-assisted steering, increasing the risk of a crash.
Remedy: BMW will notify owners, and dealers will replace and tighten the idler pulley bolt. The recall began on January 15, 2013. Owners may call BMW at 1-800-525-7417 or email BMW at [email protected].
