2016 Bmw M235i problems
The first generation of the coupé and convertible range of the BMW 2 Series subcompact executive car consists of the BMW 2 Series (F22) for the coupé version and BMW 2 Series (F23) for the convertible version. The F22/F23 was in production from November 2013 through 2021 and is often collectively referred to as the F22.
The F22 was released as the successor to the E82 1 Series coupé and E88 1 Series convertible. It is currently produced in Leipzig, previously alongside the F20 1 Series hatchback range.
The high-performance F87 M2 model was produced in the coupe body style. It is powered by the BMW N55 and BMW S55 turbocharged inline-six engines.
The United States was the most popular market for the 2 Series, accounting for one-third of all sales, followed by Germany and Great Britain.
Social links
Common 2016 Bmw M235i problems
The BMW M235i, introduced in 2016, is generally considered a reliable vehicle, particularly when subjected to regular servicing. However, there are a few common issues that owners have reported, which potential buyers should be aware of.
- Exhaust "fixing bow": The exhaust "fixing bow", a pin that connects the actuator and the actual flap, may snap, causing issues with the exhaust system.
- False low tire pressure error: The front driver side wheel may throw a false low tire pressure error, especially during snowy conditions. This is due to tire slip, which can cause the sensor to measure rotation incorrectly, indicating low tire pressure.
- Harmon Kardon system issues: The Harmon Kardon sound system in the car may occasionally have issues, with the amp kicking itself out and providing no sound from the subwoofer. This issue can be resolved by shutting off the car for about 15 minutes and restarting it.
- NAV system issues: The NAV system may occasionally reset to the fully zoomed out mode, requiring the driver to re-zoom it back in to their preference.
- Valve cover leaks: The N55 engine, found in the M235i, is known to have issues with valve cover leaks. This is a common problem in BMW cars, and it is recommended to replace both the gasket and the valve cover simultaneously to prevent further issues.
- Overheating engine: The N55 engine may experience overheating issues, which can be caused by a faulty water pump. The average quote for a water pump replacement is £341.14.
- High-pitched whining noises: High-pitched whining noises may indicate issues with the N55 engine, which could be caused by various problems, including a faulty water pump or a damaged charge pipe.
While these issues may seem daunting, it is important to note that the BMW M235i is generally considered a reliable vehicle, particularly when subjected to regular servicing. Potential buyers should be aware of these common issues and consider them when making their purchasing decision.
Is a 2016 M235i reliable?
The 2016 M235I has been a pleasure to own. It a provides outstanding performance with power and handling; striking looks and luxury. Very reliable car and provides luxurious ride.
How long do BMW M235i last?
Upon all the research I've done this N55 in m235i's seems very reliable. I've seen a couple posts of people with 150k miles+, and I would not be upset driving this car until it reaches that many miles.
What is the fuel consumption of a 2016 BMW M235i?
BMW M235i 2016 Fuel consumption
Fuel consumption for the 2016 BMW M235i is dependent on the type of engine, transmission, or model chosen. The BMW M235i currently offers fuel consumption from 7.6 to 8.5L/100km.
Is the 2016 BMW M235i twin turbo?
The M235 coupe/convertible is available in rear- or xDrive all-wheel drive. The M235i is powered by a 322-hp, 3.0-liter TwinPower turbo inline six-cylinder engine mated to either a six-speed manual transmission or an eight-speed automatic transmission.
2016 Bmw M235i car problems categorized by type of issue
After analyzing all complaints sent to the NHTSA and researching popular Bmw M235i problems, we found that the most common problems with these 2023 model year vehicles are:
- Electrical system problems
- Exterior lighting problems
- Power train problems
- Service brakes problems
- Seat belts problems
The graph below shows statistics for all 2016 Bmw M235i vehicle components and the number of complaints received.
2016 Bmw M235i complaints
The NHTSA has received 8 complaints about various vehicle components related to the 2016 Bmw M235i.
POWER TRAIN PROBLEM
- Date Of Incident: 2022-01-13
- VIN: WBA1M5C5XGV
- Components: POWER TRAIN
- Summary: Our M235I has a transmission leak "thru the wall of the case" (i.e. THROUGH THE METAL CASE) as determined by a local BMW Dealer. They are not able to provide any Technical Service Bulletins or etc. from BMW for this "leaky case" issue. But they are saying this is a KNOWN problem with the transmission cases. They are advising a new transmission for $10K. Only alternative is to install used transmission and take old electronic valve module out of existing trans and place into used transmission and hope for the best. Loss of transmission fluid could cause unit to malfunction or fail!!!
ELECTRICAL SYSTEM,SERVICE BRAKES PROBLEM
- Date Of Incident: 2021-09-24
- VIN: WBA1M5C50GV
- Components: ELECTRICAL SYSTEM,SERVICE BRAKES
- Summary: BMW 2 series cars from about 2015-2018 have faulty wiring and brake light assemblies. BMW has admitted this design flaw in the harness and light - they extended the warranty for one year. As you know, brake light failures represent a real risk. It is unreasonable for BMW to charge $900 per light to fix a safety issue caused by a design flaw that they have admitted. THE CONSUMER STATED THE PASSENGER TAIL LIGHT HAS FAILED, ALSO.
ELECTRICAL SYSTEM,EXTERIOR LIGHTING PROBLEM
- Date Of Incident: 2021-08-03
- VIN: WBA1J7C52GV
- Components: ELECTRICAL SYSTEM,EXTERIOR LIGHTING
- Summary: Rear brake light failure due to faulty wiring. Identical to the details located in this article (https://www.autoblog.com/2011/09/01/bmw-recalling-241-000-3-series-models-over-faulty-tail-lights/) for which the NHTSA had issued a recall for older BMW models in the past. This issue is common and wide-spread amongst bmw models produced between 2014 - mid 2016. After which BMW modified the wiring harness for the brake lights to fix the electrical shorting failures. This failure renders the entire housing inoperable - Brake light, turn signal and reverse lamp. Summary: OVER TIME, RESISTANCE IN THE ELECTRICAL CONTACTS MAY CAUSE ONE OR MORE REAR LAMP FUNCTIONS (TAIL LIGHT, BRAKE LIGHT, AND/OR TURN-SIGNAL), WITHIN THE VEHICLE'S BODY PANEL, TO STOP WORKING. Consequence: INTERMITTENT LIGHT OPERATION REDUCES THE ABILITY TO WARN OTHER MOTORISTS OF THE DRIVER'S INTENTIONS. THIS COULD CAUSE A VEHICLE CRASH WITHOUT WARNING. I have attached a BMW TSB (SI_B63_05_17) which outlines that BMW was aware of this issue as early as October 2017 but did not issue a voluntary recall for an issue that warranted a recall in the past. My brake light housing failed as a result of the faulty ground wire 8 months after the extended warranty on these parts lapsed resulting in an estimated $1140 in repairs for a critical safety component for which I cannot operate the vehicle safely without. The vehicle is currently with a BMW dealership for inspection and repair. Warning messages appeared after the component had completely failed while driving. Incident occurred in early August 2021.
SEAT BELTS PROBLEM
- Date Of Incident: 2021-03-05
- VIN: WBA1J7C5XGV
- Components: SEAT BELTS
- Summary: DRIVER SIDE SEATBELT IS SLOW TO RETRACT AND KEEPS GETTING TWISTED WHEN RETRACTING. YOU HAVE TO CAREFULLY HELP FEED THE BELT INTO THE B PILLAR FOR IT NOT TO DO THAT. IF NOT, IT WILL ALMOST GET JAMMED IN THE B PILLAR AND GET STUCK AND BECOMES NON-FUNCTIONAL. IT TAKES A LOT OF STRENGTH AND EFFORT TO PULL TO PULL IT BACK OUT. VERY UNSAFE BECAUSE YOU HAVE TO BE ALWAYS AWARE OF THIS DEFECT WHILE DRIVING. SOMETIMES WE HAVE TO UNFASTEN OUR BELTS WHILE DRIVING TO REACH OR ADJUST SOMETHING. AND IT USUALLY GETS JAMMED AND STUCK IN THE B PILLAR AND BECOMES NON-FUNCTIONAL. OWNED AND DRIVEN SEVERAL CARS. THIS HAS NEVER HAPPENED BEFORE WITH ANY OTHER CAR. NEVER WITH THIS REGULARITY.
FUEL SYSTEM, GASOLINE PROBLEM
- Date Of Incident: 2020-09-01
- VIN: WBA1J7C53GV
- Components: FUEL SYSTEM, GASOLINE
- Summary: TL* THE CONTACT OWNS A 2016 BMW M235I. THE CONTACT STATED THAT WHILE OPERATING THE VEHICLE THE ODOR OF FUEL WAS PRESENT. THE VEHICLE WAS TAKEN TO AN INDEPENDENT MECHANIC WHO DIAGNOSED THAT THE FUEL TANK HAD CRACKED AND NEEDED TO BE REPLACED. THE CAUSE OF THE DAMAGED FUEL TANK WAS NOT DETERMINED. THE FUEL TANK WAS REPLACED AND THE FAILURE WAS REMEDIED. THE MANUFACTURER WAS NOTIFIED OF THE FAILURE. THE LOCAL DEALER WAS NOT CONTACTED. THE FAILURE MILEAGE WAS 28,000. *LN *AS
UNKNOWN OR OTHER PROBLEM
- Date Of Incident: 2019-02-01
- VIN: WBA1J9C52GV
- Components: UNKNOWN OR OTHER
- Summary: IN LATE FEBRUARY 1, 2019, THE SUNROOF ON MY 2016 BMW M235I XDRIVE EXPLODED WHILE DRIVING ON THE GARDEN STATE PARKWAY. I WAS NOT GOING UNDERNEATH ANY OVERPASS, AND NOTHING HIT THE GLASS. THE EXPLOSION WAS UNPROVOKED. THE SUNSHADE WAS NOT CLOSED, AND THE GLASS FELL ALL OVER ME, LARGE AND SMALL SHARDS. I WAS DRIVING ABOUT 65MPH IN HEAVY MORNING RUSH HOUR TRAFFIC, AND PIECES OF GLASS FLEW OFF THE CAR AND LIKELY HIT OTHER CARS. IT WAS VERY ALARMING AND SCARY. I WAS ABOUT 5 MILES FROM A BMW DEALER AND DROVE RIGHT TO THE DEALER WHERE THE CAR IS STILL SITTING WAITING TO BE FIXED. BMW IS REPLACING THE GLASS AND SUNROOF ASSEMBLY UNDER WARRANTY. THIS WAS A VERY DANGEROUS SITUATION AND WITH THE GLASS FALLING ALL OVER ME COULD HAVE RESULTED IN INJURY TO ME, OR SOMEONE ELSE IF THERE WERE OTHERS IN THE CAR, OR OTHER SURROUNDING VEHICLES WITH THE EXPLODED GLASS FLYING EVERYWHERE.
EXTERIOR LIGHTING PROBLEM
- Date Of Incident: 2016-09-03
- VIN: WBS1H9C57GV
- Components: EXTERIOR LIGHTING
- Summary: THE CAR HAS INSTRUMENTS (SPEEDOMETER AND TACH) WITH LOW CONTRAST BETWEEN THE BACKGROUND AND LETTERING. THE INSTRUMENTS ARE HIGHLY VISIBLE WHEN THE INSTRUMENT LIGHTING IS ENABLED, BUT ARE NEARLY INVISIBLE WHEN THE LIGHTING IS OFF. THERE IS AN AMBIENT LIGHT SENSOR THAT TURNS THE INSTRUMENT LIGHTING ON AND OFF AS YOU DRIVE IN MIXED SUN AND SHADE, SO AS YOU DRIVE FROM A SHADED AREA TO A SUN-LIT AREA, THE INSTRUMENTS ALTERNATE BETWEEN VISIBLE AND INVISIBLE. IT IS DISCONCERTING AND DANGEROUS TO SUDDENLY LOSE INSTRUMENT VISIBILITY AS YOU DRIVE. THERE IS NO WAY TO SWITCH THE INSTRUMENT LIGHTS ON AT ALL TIMES, EVEN IF THE HEADLIGHTS ARE SWITCHED ON.
VISIBILITY/WIPER PROBLEM
- Date Of Incident: 2016-05-02
- VIN: WBA1J7C58GV
- Components: VISIBILITY/WIPER
- Summary: WAS TRAVELING AT 55 MPH ON AN EXIT RAMP WITH THE NEAREST CAR ABOUT 5 OR 6 CAR LENGTHS IN FRONT OF ME. SMOOTH, PAVED ROAD WITH NO DEBRIS. THE SUNROOF MADE A LOUD POP AND SHATTERED SPONTANEOUSLY, RAINING GLASS DOWN ON ME. THE GLASS HAD AN OUTWARD BEND TO IT AS IF IT HAD EXPLODED OUTWARDS WITH PRESSURE RELIEF. NO ROCKS OR DEBRIS WERE SEEN OR POSSIBLE FROM NEARBY VEHICLES GIVEN THE DISTANCES BETWEEN MY CAR AND THEIRS, AND NOTHING BEING SEEN TRAVELING THROUGH THE AIR. IT APPEARS THAT THIS IS DUE TO A FLAW IN THE CONSTRUCTION OF THE GLASS ITSELF (I.E. FLAWS IN CONSTRUCTION, IMPURITIES, ETC.), AND THAT THE SPONTANEOUS EXPLOSION OF THE GLASS WITHIN THE SUNROOF FRAME WAS NOT A RESULT OF ANY KIND OF IMPACT. THE GLASS WAS ALSO FLAWLESS IN TERMS OF NEVER HAVING BEEN NICKED BY DEBRIS. THE CAR IS A FEW MONTHS OLD WITH 3,000 MILES.
